Loggers
Memory: Non-volatile flash memory
Power: Two 9VDC Alkaline Batteries
Battery Life: Up to 1 year (depending on recording intervals)
Resolution: 12 bit
Moisture Protection: Silicon coating (prevents damage to electronics from condensation)
Temperature: -40° to +185°F (-40° to +85°C)
Humidity: 0-95% non-condensing
Storage Capacity: 81,759 time and date stamped data points including battery voltage
Sample Modes: High Speed (10 samples per second), Fixed Interval (Programmable from 1 sec to >1 year), Logarithmic, Exception
Data Overwrite: Select memory wrap or unwrap (unwrap will stop logging data once memory is full)
Clock: Synchronizes to the time and date of user's computer
Clock Accuracy: 0.0025% or 1 minute in 1 month
Clock Format: Month/Day/Year Hour/Minute/Second
Enclosure: 1-7/8 inch dia x 11-1/2 inch length (fits inside a 2 inch well), stainless steel UV protected PVC vented for barometric pressure compensation
Weight: 1.6 lbs (0.7 kg) (with battery and 25 ft cable)
Communication Port:
FL16S: RS-232 4-pin circular connector
FL16U: USB Type B
Selectable Baud Rates:
9600,19200,28800,38400,57600,115200
Water Flow Logger Vented Cable
Conductors: 4 each 22 AWG
Material: Marine grade polyurethane jacket, HD polyethylene vent tube, full foil shield
Shield: Aluminum Mylar
Outside Diameter: 0.307 inch (7.8mm)
Length: Standard 25 ft (up to 500 ft from factory)
Temperature range: -22 to 185°F (-30° to 85°C)
Weight: 0.7 oz/ft (65g/m)
Water Flow Sensor
Sensor Element: Silicone Diaphragm, Wet/Wet Transducer
Level Range: 0-3 ft
Temperature Range: 32-122°F (0-50°C)
Linearity and Hysteresis: ±0.1% FS
Accuracy:
Level: ±0.1% FS at constant temperature, ±0.2% over 32° to 70°F (0° to 21.1°C) range
Temperature: Smaller of 0.5°F or ±1% of reading
Overpressure: 2 x full scale range
Burst Pressure: 10 x full scale range
Resolution: Infinite (Analog)
Output Currents:
Level: 4-20mA ±1mA of full scale
Temperature: 0-10mA ±1mA full scale
Supply Voltage: 10-36VDC
Current Draw: Combined level and temperature output currents
Warm Up Time: 3 seconds recommended
Operating Temperature: 0° (not frozen) to +185°F (-17.8° to 85°C)
Compensated Temperature Range: 32° to 70°F (0 to 21.1°C) submerged, automatic barometric compensation
Housing:
Material: 316 Stainless Steel Outer Sleeve, PVC diffuser and strain relief
Size: 9 inch long x 1 inch dia. (22.9 cm long x 2.54 cm dia.)
Weight: ~250g (9oz)
