Rated primary current: 100A AC
Output Voltage: 1mV AC/A
Maximum input current: 130A AC (Continuous)
Amplitude accuracy: ±0.3%RD±0.02%FS (10%-100%I1n),(45Hz- 66Hz)
Phase accuracy: ±2° (10%-100%I1n)(45Hz-5kHZ)
The amplitude frequency characteristic: ±0.1% (45Hz-5kHZ)(Deviation accuracy)
Conductor impact: ±0.5 (Off-center)
The influence of external lectromagnetic fields: ≤0.1A (In AC 400A / m electromagnetic fields)
Temperature coefficient: ±0.02%/°C of the reading data
Dielectric strength: 3000 V AC rms/Continue 15 seconds(Circuits-iron core, iron core-shell)
The maximum rated voltage: 300V AC rms
Applicable standards: Safety: EN61010-2-032:2002,300V CAT III, Contamination II
EMC: EN61326:1997+A1:1998+A2:2001+A3:2003(Class A)
MECHANICAL PARAMETERS
Measurable conductor diameter: Max.15mm
Cable length: About 3m
Dimension (W x H x D): About 46×135×21 (Excluding protruding parts)
Weight: About 230g
ENVIRONMENTAL CONDITIONS
Operating temperature: 0 to 50°C (32-122°F)
Operating humidity: ≤80%RH(No condensate)
Storage temperature: -10 to 60°C (14-140°F)
Storage humidity: ≤80%RH(No condensate)
Operating environment: Indoor, altitude up to 2000 meters
