ELECTRICAL PARAMETERS
Accuracy class:
0.05%, 0.02%
Power supply: Single phase AC 220V±10% or 110 V±10%, 50/60
Hz
DC voltage output
Range: 100mV, 300mV, 1V, 3V, 10V, 100V,
300V, 600V, 1000V, (max 1000V)
Adjustment range: (0-120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Accuracy: 0.012% RD + 0.008% RG(≥1V); 0.03% RD + 0.02% RG(＜1V)
Stability: 0.005% RG / 1 min(≥1V); 0.01% RG / 1 min(＜1V)
Distortion degree: Better than 0.1% (not capacitive load)
Load Capacity: Max 25VA
Ripple contents: ≤1%
Full load regulation rate: Less than 0.01% RG
Full load regulation time: Less than 10mS
Temperature drift: 8 PPM/°C
Long-term stability: 60 PPM/year
DC current output
Range: 10uA, 30uA, 100uA, 300uA, 1mA, 3mA, 10 mA, 30mA,
100mA, 300mA, 1A, 3A, 10A, 30A( max 36A)
Adjustment range: (0-120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Accuracy: 0.03% RD + 0.02% RG
Stability: 0.01% RG/1 min
Distortion degree: Better than 0.1% (not capacitive load)
Load Capacity: 48VA
Ripple contents: ≤1%
Full load regulation rate: Less than 0.01% RG
Full load regulation time: Less than 10mS
Temperature drift: 8 PPM/°C
Long-term stability: 60 PPM/year
DC Power output
Accuracy: 0.05%
Stability: 0.01% RG / 1 min
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 440x360x160
Weight (kg): 12
ENVIRONMENTAL CONDITIONS
Operating temperature: 0°C ~ 40°C
Storage conditions: -30°C ~ 60°C
Relative humidity: ≤85%
