Working Positions: 9
Control Mode: PLC Control and Touch Screen Display
Counter Range: 0~999999 times
Test Pressure
Abrasion Test:
Specimen holder: (198±2)g
Larger loading piece: (597±5)g
The sum mass:(795±7)g, for workwear, upholstery, bed linen and fabrics for technical use (nominal pressure of 12kpa)
Specimen holder: (198±2)g
Smaller loading piece:(397±5)g
The sum mass: (595±7)g, for apparel and household textiles, excluding upholstery and bed linen (nominal pressure of 9kpa)
Pilling Test:
Stainless steel loading piece: (155±1)g
Specimen holder: (260±1)g
The sum mass: (415±2)g
Holder Effective Diameter:
Abrasion Holder: φ(28.65 + 0.05)mm
Pilling Holder: φ(90± 0.10)mm
Rotational Speed: 50±2r/min
Pressing Weight: Mass:(2.5 ±0.5)
Diameter: φ(120±10)mm
Power Supply: AC220V 50/60HZ 500W
Dimensions (L×W×H): 850x650x350mm
Weight: 150kg
Accesories:
Abrasion Weight and Holder: 1set
Pilling Weight and Holder: 1set
Standard Abradents Fabric: 2pcs for each head
Standard Backing Foam 38mm box: 60pcs
Standard Woven Felt Discs 140mm: 2pcs for each head
Standard Woven Felt Discs 90mm: 2pcs for each head
Sample Cutting Template (038mm, 090mm, 0140mm): 1pc each size
Pressing Weight: 1pc
Auxiliary Device for Specimen Mounting: 1pc
Steel Ball: 3pcs
Power Line: 1pc
Optional accesories:
EMPA Photographic Standards for Pilling Test (3x4 knitted)
EMPA Photographic Standards for Pilling Test (3 x 4 woven)
SM 50 Photographs for Pilling Test IWS+ ASTM Optional 4 Sets 1-5 (Plain, Twill A, Twill B, Blanket)
Standard Abradents Fabric
Standard Backing Foam φ38mm
Standard Woven Felt Discs φ140mm
Standard Woven Felt Discs φ90mm
Sample Cutter φ38mm
Sample Cutter 090mm
Sample Cutter φ140mm
