Fall Time: 21 ns
Rise Time: 28 ns
Technology: SiC
Unit Weight: 6 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Qg - Gate Charge: 29 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 138 W
Vgs - Gate-Source Voltage: - 5 V, + 15 V
Typical Turn-On Delay Time: 32 ns
Typical Turn-Off Delay Time: 34 ns
Id - Continuous Drain Current: 17 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 4.7 S
Rds On - Drain-Source Resistance: 160 mOhms
Vds - Drain-Source Breakdown Voltage: 1.7 kV
Vgs th - Gate-Source Threshold Voltage: 2.7 V
