Vishay General Semiconductor BPV11 ຊິບ T-1.75 450 ຫາ 1080nm +/-15 ອົງສາ

Width: 5.75 mm

Height: 8 mm

Length: 5.75 mm

Wavelength: 850 nm

Dark Current: 50 nA

Light Current: 10 mA

Mounting Style: Through Hole

Peak Wavelength: 850 nm

Lens Color/Style: Water Clear

Pd - Power Dissipation: 150 mW

Half Intensity Angle Degrees: 15 deg

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C

Maximum On-State Collector Current: 50 mA

Collector- Emitter Voltage VCEO Max: 70 V

Collector-Emitter Breakdown Voltage: 70 V

Collector-Emitter Saturation Voltage: 130 mV
