GENERAL
Data logging: 21k points
Profile storage: 14 profiles
Sampling rate: 5-4800 SPS
Internal resolution: 24 bits
Integrated digital filter: 50 Hz/60 Hz Rejection (120 dB)
Operating temperature: –4 to 158°F (–20 to 70°C)
Storage temperature: –22 to 176°F (–30 to 80°C)
Weight: 1.9 lb (862 g)
Internal shunt resistance value: 150 kOhm
Readout nonlinearity: ± 0.005% of FSR
Front panel IP rating: IP50
STRAIN GAUGE mV/V INPUT
Bridge Excitation Precision: 5.000 VDC
Standard Input Range: ± 2 mV/V (factory default)
Optional Input Range: Up to ± 500 mV/V
Min. Bridge Resistance: 30 Ohm
Reading Error**: ± 0.15% of 2 mV/V
VOLTAGE INPUT
Standard Input Range: ±12 VDC
Reading Error**: ± 0.06% of 10 VDC
CURRENT INPUT
Standard Input Range 0-30 mA
OUTPUT
Analog Voltage: 0–5 or ±5 VDC*
Minimum Load Impedance (Voltage): 10 kOhm
Analog Current: 0-20, 4-20, 0-25, 5-25 mA*
Maximum Load Impedance (Current): 40 Ohm
2 Individual Relay Outputs: 110 V/100 mA max, 1 mS response time
External Supply Output: 24 VDC @ 100 mA max
USB: Digital Packetized Data
ASCII Output Update Rate: 5 SPS
POWER ADAPTER
Input: 90–264 VAC
Frequency: 47–63 Hz
Input Current: 0.35 A rms @ 120 VAC; 0.25 A @ 240 VAC
Output: 15 VDC @ 1.2 A
