Parameter
Power Supply: 16 ~ 26 VDC
Current Consumption: 30mA, MAX 100mA
Load Impedance: 14000 Ohm
Sensor Impedance: 350/754 ~ 5000 Ohm
Bandwidth (Setting 1): 1000 Hz
Bandwidth (Setting 2): 100002 Hz
Bandwidth (Setting 3): 250003 Hz
Common Mode Rejection Ratio: 120 dB
Noise: 10 mVp-p
Output Span range: –10 ~ 10 % of FSR
Output Zero range: –10 ~ 10 % of FSR
Gain Drift with Temperature: –25 ~ 25 PPM of FSR
Nonlinearity: 0.01 ~ 0.01 % of FSR
Zero Drift with Temperature: –25 ~ 25 PPM of FSR
Operating Temperature: 0 ~ 70°C
Storage Temperature: –40 ~ 85°C
Relative Humidity: 95% at 39°C
Physical Features
Material: Stainless steel cover with aluminum body fastened by magnets
Protection: IP50
Weight (approx.): 0.23 lb (104 g)
Power: LED Indicated
Conformity
RoHS: 2011/65/EU
CE: EN61326-1:2013; EN55011:2009 (Amended by A1:2010) Class 1 Certification for Aerospace and Medical Grade Device
