Pressure Measurement (Nominal Piston Area (cm²) / Pressure Range (kPa) / Resolution (Pa)):
- 10 cm² / - 44 kPa / 0.01 Pa
- 20 cm² / 0 - 22 kPa / 0.005 Pa
- 45 cm² / 0 - 9 kPa / 0.002 Pa
- 100 cm² / 0 - 3.4 kPa / 0.001 Pa
Uncertainty (typical) ± (0.005 % reading + 0.02 Pa)
Pneumatic
Media Compatibility: Clean, dry air or non-corrosive gas
Air Supply Pressure (control unit): Maximum 10 bar gauge, Minimum 5 bar gauge
Pneumatic Connections
Air supply – 6 mm push-on tube connector
Flow return – 6 mm push-on tube connector
Equalise valve pilot – 6 mm push-in tube connector
Pressure and reference ports – ¼ BSP female threaded
Electrical
Supply Voltage: 115 – 230 Vac, 50-60 Hz
Electrical connections
Power: detachable screw locking circular connector
USB: Type B USB connector for printer or PC connection
Environmental
Storage Temperature
Minimum: -10 °C
Maximum: 70 °C
Operating Temperature
Minimum: 10 °C
Typical: 18 – 22 °C
Maximum: 40 °C
Construction
Enclosure: Aluminium housing with anodised finish. Suitable for bench or floor mounting
Dimensions: H 530 mm x W 345 mm x D 350 mm (when fitted on bench top stand)
Weight: 35 kg ± 0.5 kg
