Leak Measurement
Leak ranges: ±200.0Pa / ±2.000kPa / ±20.00kPa
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: Automatic
Span: < ±0.15% per °C
Long Term Drift (span) < ±1% per year
Pressure Measurement
Pressure Ranges:
±99.99mbar / ±200.0mbar / ±999.9mbar
-1bar to +4.000bar / -1bar to +8.000bar / -1bar to +9.999bar / -1bar to +14.00bar / -1bar to + 30.00bar
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: < ±0.05% per °C
Span: < ±0.1% per °C
Long Term Drift (span) < ±1% per year
Electrical
Supply Voltage 24VDC ±10% < 500mA
Electrical connections
Power: 2 way detachable screw terminal
Outputs: 20 way detachable screw terminal
Inputs: 16 way detachable screw terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
LAN: RJ45 connector, 10base-T/100base-TX Ethernet
USB: 1 x USB Type A connector, 1 x USB Type B connector
Control Inputs Up to 24 Opto-isolated, active high or active low. 5VDC to 24VDC into 10K
Control Outputs Up to 32 Active High transistor output (PNP). 12VDC to 45VDC, 120mA (per channel)
Pneumatic
Media Compatibility: Clean dry air or non-corrosive gas
Air Supply Pressure: Maximum 10bar gauge, Minimum 5bar gauge
Regulator Supply Pressure: Maximum 16bar gauge or 35bar for 30bar option
Pneumatic Connections:
Air supply: 6mm push-in tube connector
Regulator supply and output: 8mm push-in tube connector
Test/Reference: 1/8” BSPF
Up to 5 programmable pneumatic outputs: 4mm push-in tube connectors
Leak Tightness: < 0.2cc/Hour
Construction
Enclosure Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case 482 x 133 x 296 mm (W x H x D)
Dimensions – Bench Case 366 x 147 x 296 mm (W x H x D)
Weight 8.5 kg ± 0.5 kg
