Leak Measurement
Leak ranges: ±200.0 Pa / ±2.000 kPa / ±20.00 kPa
Accuracy @ 20°C
200 Pa and 2 kPa models:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
20 kPa model: < ± (1% range + 1 digit)
Resolution: 4 digit display
Temperature Coefficients:
Zero: Automatic
Span: < 0.15% per °C
Long Term Drift (span): < ± 1% per year
Pressure Measurement
Pressure Ranges
±99.99mbar / ±200.0mbar / ±999.9mbar
-1bar to +4.000bar / -1bar to +8.000bar / -1bar to +9.999bar / -1bar to +14.00bar / -1bar to + 30.00bar
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution: 4 digit display
Temperature Coefficients:
Zero: < 0.05% per °C
Span: < 0.1% per °C
Long Term Drift (span): < ± 1% per year
Electrical
Supply Voltage 24 VDC ± 10% < 500 mA
Electrical connections:
Power: 2 way detachable screw terminal
Outputs: detachable screw terminal
Inputs: detachable screw terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
Control Inputs: Up to 12 Opto-isolated, active high or active low. 5 VDC to 24 VDC into 10 K
Control Outputs: Up to 16 Active High transistor output (PNP). 12 VDC to 45 VDC, 120 mA (per channel)
Pneumatic
Media Compatibility: Clean dry air or non-corrosive gas
Air Supply Pressure: Maximum 10 bar gauge, Minimum 5 bar gauge
Regulator Supply Pressure: Maximum 16 bar gauge or 35 bar for 30 bar option
Pneumatic Connections:
Air supply – 6 mm push-in tube connector
Regulator supply and output – 8 mm push-in tube connector
Test/Reference 1/8” BSPF
Pneumatic pilot outputs - 4 mm push-in tube connectors
Leak Tightness < 0.2cc/Hour
Construction
Enclosure Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case 267 x 133 x 296 mm (W x H x D)
Dimensions – Bench Case 232 x 147 x 296 mm (W x H x D)
Weight 5 kg
