Number of Phases: 1 or 3
Bandwidth: dc to 3 MHz or dc to 10 MHz depending on input module
Basic Accuracy: 0.2%, 0.1% or 0.03% depending on input modules
Sampling Rate: 0.33 MHz or 1 MHz depending on input modules
Voltage Input Range: 0.3 to 1000 V
Current Input Range (direct, not via shunt): 0.03 mA – 20 A depending on input module
Current Input Range via shunt: Table Shunts on page 10
Display: Color, 5.7“ / 144 mm - 320 x 240 pixel
Measured data memory: 4 MB
Memory for Settings: Standard
Fast Fourier Transformation (FFT): To the 40th harmonic
RS232 Interface: Standard
PI1 Process Interface (8 analog/impulse inputs and 4 analog outputs): Optional
IEEE 488/GPIB Interface: Optional
Fluke NormaView PC Software (for data download, analysis): Standard
Includes:
Power supply cable
5.7“ / 144 mm color display
RS232/USB interface for data download
Space for three power-phases and options
Fluke NormaView PC software
User’s manual
Test certificate
Calibration values
