Function Measure or Source
Voltage 0 to 100 mV/ 0.01 % Rdg + 2 LSD
0 to 20 V (source)/ 0.01 % Rdg + 2 LSD
0 to 30 V (measure)/ 0.01 % Rdg + 2 LSD
mA 0 to 24 / 0.01 % Rdg + 2 LSD
mV (TC terminals): -10.00 mV to +75.00 mV/ 0.01 % Rdg + 2 LSD
Resistance: 5 Ω to 4000 Ω/0.015 %
Frequency: 2.0 to 1,000 CPM, 1 to 1100 Hz, 1.0 to 10.0 kHz, 10.0 to 15.0 kHz
Loop Supply: 24 V dc/ 10 %
Thermocouples J, K, T, E, L, N, U, C, BP, XK
Thermocouples B, R, S
RTDs: Cu 10 Ni 120 (672),Pt 100, 200, 500,1000 (385)Pt 100 (3916),Pt 100 (3926) Cu 10
Simultaneous Function:
24.000 mA DC
24.000 mA DC with 24 V loop supply
100.00 mV DC
30.000 V DC measure
Thermocouple J, K, T, E, R, S, B, M, L, U, N, C, BP, XK
RTD Ni120; Pt100 (392); Pt100 (JIS); Pt100, 200, 500, 1000 (385), Cu 10
Pressure (requires Fluke 700PXX Modules) Option
Frequency; Squarewave, 1 CPM to10 kHz;fixed amplitude 5 V p-p
Includes:
One set of AC72 alligator clips
One set of stackable test leads
One set of TL75 testleads
User manuals
NIST- traceable calibration report and data
