Range/ Basic Accuracy:
DC volts: 50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V/ 0.025 %
AC volts: 50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V/ 0.4 % (True-RMS)
DC current: 500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A/ 0.05 %
AC current: 500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A/ 0.6 % (True-RMS)
Temperature (excluding probe): -200.0 °C to 1350.0 °C (-328.0 °F to 2462.0 °F)/ 1.0 %
Resistance: 500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ,5.0000 MΩ, 50.00 MΩ, 500.0 MΩ/ 0.05 %
Capacitance: 1.000 nF,10.00 nF 100.0 nF, 1.000 μF, 10.00 μF, 100.0 μF, 1000 μF, 10.00 mF, 100 mF/ 1.0 %
Frequency: 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz/ 0.005 % + 1
Connectivity: Optional infrared connector via Fluke ir3000 FC
General Specifications:
Maximum voltage between any terminal and earth ground: 1000 V
Battery type: 6 AA alkaline batteries, NEDA 15A IECLR6
Battery life: 100 hours minimum, 200 hours in logging mode
Temperature: Operating: -20 °C to 55 °C; Storage: -40 °C to 60 °C
Relative humidity: 0 to 90 % (0 t 37 °C), 0 to 65 % (37 °C to 45 °C), 0 to 45 % (45 °C to 55 °C)
Electromagnetic compatibility: EMC EN61326-1
Vibration: Random vibration per MIL-PRF-28800F Class 2
Shock: 1 meter drop per IEC/EN 61010-1 3rd Edition
Size (HxWxL): 22.2 cm x 10.2 cm x 6 cm (8.75 in x 4.03 in x 2.38 in)
Weight: 870.9 g (28 oz)
Multiple on screen displays: Yes
LoZ: Yes
50 ohm range: Yes
Filter for measurements on motor drives: Yes
True-RMS AC bandwidth: 100 kHz
dBV/dBm: Yes
DC mV resolution: 1 μV
Megohm range: Up to 500 MΩ
Conductance: 50.00 nS
Continuity beeper: Yes
Temperature (°C and °F): -200 °C to 1350 °C
Battery/fuse access: Yes/Yes
Elapse time clock: Yes
Time of day clock: Yes
Min-Max-Avg: Yes
Frequency: Yes
Duty cycle/pulse width: Yes
Info button on board help: Yes
Hold: Yes
Isolated optical interface: Yes
Auto/touch hold: Yes
Reading memory: Yes
Log to PC: Yes
On board logging with TrendCapture: Yes
Logging memory up to: 15,000 readings
Wireless connectivity (optional): Yes
