Pressure Source and Milliamp Measurement to calibrate and maintain almost any pressure device
Integrated pump
Measure Pressure: (internal sensor)
Accuracy: 0.025% full scale
Note: Dry air, non-corrosives only
Range: -12 PSI to 30 PSI, (-850 mbar to 2 bar, -85 to 206.84 kPa)
Resolution: 0.001 psi, 0.1 mbar, 0.01 kPa
Over Pressure: 5x Full Scale
Functions: zero, min/max, hold, damp
Maximum voltage: 30 volts: Non-operating
Size: 216 mm x 94 mm x 66 mm
Weight : 992 g
Power: 9V battery
Display: LCD, 5 digit
include:
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Test Leads and Alligator Clip
Two 9V alkaline batteries
NIST - Traceable calibration report and data
Datasheet
Manual
| Technical Specifications |
| Standard |
| 718 Series |
|
| Measure Pressure |
(internal sensor) |
| Accuracy |
0.025% full scale |
| Functions |
zero, min/max, hold, damp |
| Note: |
Dry air, non-corrosives only |
| |
|
| 718 1G |
|
| Range: |
-1 PSI to +1 PSI, -68.9 mbar to 68.9 mbar (-6.89 kPa to 6.89 kPa) |
| Resolution: |
0.0001 psi, 0.001 mbar, 0.0001 kPa |
| Over Pressure: |
5x Full Scale |
| Functions: |
Zero, Min, Max, Hold, Damp |
| |
|
| 718 30G |
|
| Range: |
-12 PSI to 30 PSI, (-850 mbar to 2 bar, -85 to 206.84 kPa) |
| Resolution: |
0.001 psi, 0.1 mbar, 0.01 kPa |
| Over Pressure: |
5x Full Scale |
| Functions: |
Zero, Min, Max, Hold, Damp |
| |
|
| 718 100G |
|
| Range: |
-12 PSI to 100 PSI, (-850 mbar to 7 bar, -85 to 689.48 kPa) |
| Resolution: |
0.01 psi, 0.1 mbar, 0.01 kPa |
| Over Pressure: |
2x Full Scale |
| Functions: |
Zero, Min, Max, Hold, Damp |
| |
|
| 718 300G |
|
| Range: |
-12 PSI to 300 PSI, (-850 mbar to 20 bar, -85 to 2068.42 kPa ) |
| Resolution: |
0.01 psi, 1 mbar, 0.1 kPa |
| Over Pressure: |
375 PSI 25 bar |
| Functions: |
Zero, Min, Max, Hold, Damp |
|
| Fluke 718 series via using 700 Series Pressure Modules |
| Range: |
29 pressure modules, 0 – 1 in H20 to 10,000 psi, 2.5 mbar to 700 bar. Over pressure per pressure module specs |
| Resolution: |
Per pressure module specs |
| Accuracy: |
To 0.025 % of full span, per pressure module specs |
| Functions: |
Zero, Min, Max, Hold, Damp |
| |
Note: media compatibility per pressure module specs |
|
| Fluke 718 series via built in pump |
| Range: |
-12 PSI or -850 mbar to full scale Supported Pressure Units; psi, in H20 (4 °C), in H20 (20 °C), cm H20 (4 °C), cm H20 (20 °C), bar, mbar, kPa, inHg, mmHg, kg/cm |
| Loop Power: |
Range: 24 V dc |
| |
Accuracy: +/- 10 % |
| |
Note: Drive; 20 mA into 1000 Ω for battery > 6.8V; 700 Ω for battery 5.8 to 6.8 V |
| mA Measure: |
Range: 0 mA to 24 mA |
| |
Resolution: 0.001 mA |
| |
Accuracy: 0.015 % + 1 count |
|
| General Specifications |
| Maximum voltage |
|
| Temperature |
|
| Operating Temperature |
|
| Relative Humidity |
| |
95 % (10 °C to 30 °C); 75 % (30 °C to 40 °C); 45 % (40 °C to 50 °C); 35 % (50 °C to 55 °C) |
|
| Operating Altitude |
|
| Shock |
|
| Vibration |
| |
Random, 2 g, 5 Hz – 500 Hz |
|
| Safety |
| |
CSA C22.2 No. 1010.1: 1992 |
|
| EMC |
| |
EN50082-1: 1992 and EN55022: 1994 Class B |
|
| Size |
| |
216 mm x 94 mm x 66 mm (8.50 in x 3.72 in x 2.60 in) |
|
| Weight |
|
| Power, battery life |
| |
9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline; two batteries in 718 |
|
| Battery Life |
| |
4 to 20 hours typical, depending on functions used |
|
