Voltage DC Range: 0 to ±1020V/±0.01% of setting
Current DC Range: 0 to ±20.5A/ ±0.05% of setting
Resistance Range: 0 to 190 MO, 19 values in x1 and x1.9 : ±0.025% of setting
Voltage AC Range: 1 mV to 1020V (45Hz to 1 kHz, Sine)/: ±0.1% of setting
Current AC Range:29 mA to 20.5A (45 Hz to 1 kHz, Sine)/ ±0.1% of setting
DC Power Range:10.9 mW to 20.5 kW/ ±0.11% of setting
AC Power Range: 10.9 mW to 20.5 kW (45-65 Hz, PF=)/ ±0.36% of setting
Phase Range: 0 to ± 179.99° (45 Hz to 1 kHz) / ±0.25° of setting
Frequency Range: 45 Hz to 1 kHz / ±50 ppm of setting
Standard Interfaces: RS-232 and Ethernet
Line Power: Line Voltage (selectable): 100V, 120V, 220V, 240V (47 to 63 Hz)
Power Consumption: 600 VA
Dimensions: 19.3 cm x 43.2 cm x 53.8 cm
Weight: 22 kg
Option
5080A/MEG: Multi-Product calibrator with Megohm Meter Calibration Option
5080A/SC: Multi-Product Calibrator with Oscilloscope Calibration Option
5080A/SC/MEG: Multi-Product Calibrator with Megohm Meter and Oscilloscope Calibration Option
5080/CAL: calibration software
9100-200: 10/50 Turn Current Coil
5500A/COIL: 50-Turn Current Coil
5080A: Megohm Meter Calibration Option
5080A Megohm Meter Calibration Option
5080A/CASE: 5080A/CASE
|
Technical Specifications |
|||||
|
Voltage DC |
|
||||
|
Current DC |
|
||||
|
Resistance |
|
||||
|
Voltage AC |
|
||||
|
Current AC |
|
||||
|
DC Power |
|
||||
|
AC Power |
|
||||
|
Phase |
|
||||
|
Frequency |
|
||||
|
General Specifications |
||||
|
Warm up Time |
|
|||
|
Settling Time |
|
|||
|
Standard Interfaces |
|
|||
|
Temperature Performance |
|
|||
|
Temperature Coefficient |
|
|||
|
Relative Humidity |
|
|||
|
Altitude |
|
|||
|
Safety |
|
|||
|
Analog Low Isolation |
|
|||
|
EMC |
|
|||
|
Line Power |
|
|||
|
Power Consumption |
|
|||
|
Calibration Documentation |
Report of calibration with data included; 17025 accredited report optional |
|||
|
Dimensions |
|
|||
|
Weight (without options) |
|
|||
|
Absolute Uncertainty Definition |
|
|||
|
Specification Confidence Interval |
|
|||
