Internal Piezoelectric Accelerometer
Sensitivity (typical): 10.00 mV / m/s² ± 5% (1 g = 9.8 m/s²)
Measurement
Acceleration
Range: 0.1 m/s² to 199.9 m/s² peak (rms √2)
Resolution: 0.1 m/s²
Accuracy
± (5 % + 2 dgt) (LO: 10 Hz to 1 kHz)
± (10 % + 5 dgt) (HI: 1 kHz to 10 kHz)
Velocity
Range: 0.1 mm/s to 199.9 mm/s rms
Resolution: 0.1 mm/s
Accuracy: ± (5% + 2 dgt) (10 Hz to 1 kHz)
Displacement
Range: 0.001 mm to 1.999 mm peak-peak (rms 2√2)
Resolution: 0.001 mm
Accuracy: ± (5 % +2 dgt) (10 Hz to 1 kHz)
Piezoelectrical Accelerometer
Typical frequency response: 10 Hz to 15 kHz
Amplitude Units
Acceleration: g, m/s²
Velocity: mm/s
Displacement: mm
External Piezoelectrical Accelerometer
DC bias voltage: 6 V dc to 7 V dc
DC bias current: 3.5 mA
Battery: 2 AAA, IEC LR03
Battery life: 25 hrs for measurement
Dimensions (L x W x H): 24.1 x 7.1 x 5.8 cm
Weight: 220 g
Audio port: Stereo audio output jack (3.5 mm Audio Plug)
External sensor port: M12 plug
Environment
Operating temperature: -10 °C to 50 °C
Storage temperature: -30 °C to 60 °C
Operating humidity: 30% to 90% RH (non-condensing)
Operating altitude: 2,000 m
Storage altitude: 12,000 m
Ingress Protection: IP 40
Vibration limit: 500.0 m/s² peak
Drop test: 1 m
