- Imaging and optical data:
• IR resolution: 80 × 60 pixels
• Digital image enhancement: No
• Thermal sensitivity/NETD: <70 mK
• Field of view (FOV): 51° × 66°
• Minimum focus distance: 0.3 m (0.98 ft)
• Distance to spot ratio: 24:1
• Pseudo dual range: No
• Image frequency: 8.7 Hz
• Focus: Fixed
- Detector data:
• Focal plane array/spectral range: Uncooled microbolometer/7.5–14 µm
• Detector pitch: 17 μm
- Image presentation:
• Display resolution: 320 × 240 pixels
• Screen: 2.4 in. portrait, 80° viewing angle
• Image adjustment: Automatic
• Image modes:
MSX® (Multi Spectral Dynamic Imaging)
Visual (with temperature reading)
• Gallery: Yes
- Measurement and analysis:
• Object temperature range: -25°C to 300°C (-13°F to 572°F)
• Accuracy:
50°C to 100°C (122°F to 212°F) - acc. of ±1.5°C (±3°F)
0°C to 50°C/100°C to 300°C (32°F to 122°F/212°F to 572°F) - acc. of ±2.5°C(±5°F)
-25°C to 0°C (-13°F to 32°F) - acc. of ±3°C (±7°F)
• Minimum measurement distance: 0.26 m (0.85 ft.)
• Spotmeter: Center spot on/off
• Color palettes: Iron, Rainbow, Whitehot, Blackhot, Arctic, Lava
- Storage of images
• Storage media: 4 GB
• Image storage capacity: 50,000 images
• Image file format: JPEG with spot temp in meta tag
- Digital camera:
• Resolution: 2 MP (1600 × 1200 pixels)
• Focus: Fixed
• Field of view: 71° × 56°, adapts to the IR lens
- Worklight and Laser:
• Worklight: LED on/off
• Light output: 100 lumens
• Bullseye laser pointer: Indicating the size of the measurement area
• Laser type: Class 1
- Data communication interfaces:
• Interfaces: USB 2.0
• USB standard: USB Type-C High Speed; data transfer/power
- Power system:
• Battery type Rechargeable Li-ion, 3.7 V battery
• Battery operating time: 5 hours of scanning (LCM medium brightness)
4.5 hours with laser on (LCM medium brightness)
• Battery charge life: 30 days minimum
• Charging system: Battery is charged inside the camera; 4 hrs to 90%,
6 hrs. to 100%
• Power management Adjustable: off, 5 minutes, 15 minutes, 30 minutes
- General:
• Operating temperature range: -10°C to 45°C (14°F to 113°F)
• Encapsulation: IP54 (IEC60529)
• Shock: 25 g (IEC 60068-2-27)
• Vibratio: 2 g (IEC 60068-2-6)
• Drop test: Designed for 2 m (6.56 ft.)
• Safety: CE/CB/EN61010/UL
• Weight: 0.394 kg (13.9 oz)
• Size (L × W × H): 210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
• Tripod mounting: UNC ¼”-20
