General
Detector Type: Long-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H): 13.7", 18.4", 12.8" (348mm, 467mm, 326 mm)
Input Voltage: 24 VDC (21-30 VDC) 24 VAC (21-30 VAC)
Power Consumption: 24 VAC: 85 VA (max w/o heaters) 215 VA (max w/heaters) 24 VDC: 65 W (max w/o heaters) 195 W (max w/heaters)
Thermal Array Format: 640 × 480
Thermal Effective Resolution: 307200.0
Thermal E-Zoom: Continuous E-Zoom to 4×
Thermal Focus Range: Athermalized, Focus-Free
Thermal Pixel Pitch: 17 µm
Thermal Spectral Range: 7.5µm - 13.5µm
Weight: 36 lbs. (16.4 kg)
Zoom: 30X optical zoom with autofocus and 12X digital zoom
Environmental
De-Icing/Anti-Icing: MIL-STD-810F, Method 521.1; - De-Icing
Humidity: 0-95% relative
IP Rating (dust & water ingress): IP66
Operating Temperature Range: -40°C to 70°C cold start
Shock: MIL-STD-810F "Transportation"
Storage Temperature Range: -55°C to 85°C
Vibration: IEC 60068-2-27
Measurement & Analysis
Programmable Presets: 256.0
Other
Type of Sensor: Full HD 1080p 1/2.8-type Exmor R CMOS
PTZ
Pan Angle/Speed: Continuous 360°; 0.1° to 60°/sec
Tilt Angle - Speed: +90° to -90°; 0.1° to 30°/sec
System Integration
Ethernet: Yes
External Analytics Compatible: Yes
Network APIs: FLIR SDK FLIR CGI ONVIF Profile S
Serial Control Interfaces: RS-232/-422; Pelco D, Bosch
Supported Protocols: IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, SCP
Thermal Camera
Focal Length - Thermal: 35 mm
Thermal Frame Rate: NTSC: 30 Hz PAL: 25 Hz / 8.3 Hz
Thermal Image Settings: Auto AGC, Dynamic Detail Enhancement (DDE), Sensitivity
Video & Recording
Composite Video NTSC or PAL: Yes: Hybrid IP & Analog
Video Compression: Thermal: Two independent channels of H.264 & M-JPEG; Visible: Two independent channels of H.264 & M-JPEG
Video Image Uniformity Optimization: Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
Video Streaming Resolution: Thermal: QVGA to VGA; Visible: VGA to HD
Video Thermal AGC Modes: Linear AGC, Histogram AGC, Dynamic Detail Enhancement (DDE), Sensitivity
Video Thermal AGC Region of Interest [ROI]: Default, Presets and User definable to insure optimal image quality on subjects of interest
Visible Camera
Array format: 640 × 480
Field of view (FOV): 17°×14°
f-number: F1.6 to F4.7
Focal Length: 4.3 mm (wide) to 129.0 mm (tele)
Lens Field of View: 63.7° (wide end) to 2.3° (tele end)
Low Light Sensitivity: Color: 0.01 lx (F1.6, AGC on, 1/30s)
Noise Reduction: Yes (6 steps)
Sensitivity: <35mK @ 25c F# 1.0
Sensor Illumination: Back Light Compensation
WDR: 120db
