Imaging & Optical
Adjustable Viewfinder: Built-in, tiltable OLED, 800 × 480 pixels
Camera f-number: 1.59
Color LCD: 4", 640 × 480 pixel rotatable, touchscreen LCD
Color Palettes: Arctic, White hot, Black hot, Iron, Lava, Rainbow, Rainbow HC
Detector Pitch: 30 μm
Detector Type: Focal plane array (FPA), cooled InSb
Display Frame Rate: 60 Hz
Field of View: 14.5° × 10.8°
Focus: Auto & Manual
Image Modes: IR image, visual image, high sensitivity mode (HSM), noise reduction filter
IR Resolution: 320 × 240 thermal resolution (76,800 pixels)
Laser Spot: Yes
MPEG Video Recording: Yes
On Camera Display: Widescreen 800 × 480 pixel LCD, Tiltable 800 × 480 pixel OLED viewfinder
Radiometric IR Video: RTRR (.csq), Over UVC
Radiometric JPG: Yes
Sensor Cooling: Stirling Microcooler (FLIR MC-3)
Spectral Range: 4.2 µm to 4.4 µm
Video Recording & Streaming: H.264 to memory card
Zoom: 1 – 8× continuous, digital zoom
Measurement & Analysis
Gas Sensitivity: CO₂: <1.1 ppm x m (ΔT = 10°C, Distance = 1 m)
Recording: MultiREC Recording; Record multiple files automatically in customizable order
Spot Meter: 10
Thermal Sensitivity: <15 mK @ 30°C (86°F)
Communication & Data Storage
Communication Interfaces: USB 2.0, Bluetooth via headset, Wi-Fi, HDMI
Image File Format: Standard JPEG, measurement data included. Infrared-only mode
Storage Media: Removable SD card
Video Out: HDMI, DVI
General
Size [L x W x H ] w Lens: 251.6 mm × 164.5 mm × 170.9 mm (9.9 in × 6.48 in × 6.73 in)
Weight [incl lens & batteries]: 3 kg (6.18 lb)
Power
Battery operating time: >2.5 hours at 25°C (68°F) and typical use
Battery type: Rechargeable Li-ion battery; 7.4 V, charged in camera or separate 2-bay charger
Charging Time: 2.5 hours to 95% capacity, charging status indicated by LEDs
Start Up Time: Typically 7 min. at 25°C (77°F)
Environmental & Certifications
Encapsulation: IP54 (IEC 60529)
Mounting: UNC ¼"-20
Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)
Shock & Vibration: Shock: 25 g (IEC 60068-2-27); Vibration: 2 g (IEC 60068-2-6)
Storage Temperature Range: -30°C to 60°C (-22°F to 140°F)
