General
Detector Type: Long-Life, Uncooled VOx Microbolometer
Focus Range: Athermalized, Focus-Free
Input Voltage: 24 VAC(±10%); Universal POE injector
Zoom: Optical Zoom: 31
Compliance & Certifications
Compliance and Certifications: FCC Part 15 (Subpart B, class A) CE Marked RoHS IP66 WEEE NEMA 4X IEC 62368
Environmental
Humidity: 0-95% relative
IP Rating (dust & water ingress): IP66
Operating Temperature Range: -40°C to 60°C
Shock: IEC 60068-2-27
Storage Temperature: -55°C to 85°C
Vibe: IEC 60068-2-64
Measurement & Analysis
Programmable Presets: 256
PTZ
Pan Speed: Continuous 360°; 0.1° to 90° /sec
Tilt Speed: -10° to 190°; 0.1° to 60°/sec
System Integration
Ethernet: 10/100/1000 Mbps
Network APIs: FLIR SDK, FLIR CGI, ONVIF Profile S
Streaming Resolution: Thermal: QVGA to VGA
Visible: VGA to 4k
Supported Protocols: IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Thermal Camera
Optical Characteristics: FOV: 12° × 9°
Focal Length: 18 mm
Pixel Pitch: 12 µm
Thermal Frame Rate: NTSC: 30 Hz or PAL: 25 Hz / 8.3 Hz
Thermal Image Settings: Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Video & Recording
Video Compression: Thermal: One channel of H.264 & M-JPEG
Visible: Two independent channels of H.264 & M-JPEG
Video Image Uniformity Optimization: Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
Visible Camera
AGC: Default, Presets and User definable to insure optimal image quality on subjects of interest
Array format: 320 × 240
Focal Length: 6.5mm - 202mm
Lens Field of View:
Visible:
HFOV: 61.8° - 2.15°
VFOV: 36.65° - 1.2°
Sensitivity:
Visible:
Color: 0.25 Lux (@ (f1.6 AGC On, 30FPS)
B/W: 0.10 Lux (@ (f1.6 AGC On, 30FPS)
Spectral Range: 7.5 μm to 13.5 μm
