Detector Data
Detector pitch: 17 µm
IR resolution: 320 × 240
Visual resolution: 1280 × 960
Focal plane array/spectral range: <30 mK to <50 mK, lens dependent
Lenses: 6°, 14°, 24°, 42°, 80°, FlexView® Dual FOV (24°/14°), FlexView® Dual FOV (42°/24°) lenses
IR camera focus: One-shot contrast, motorized, manual
Measurement
Object temperatures: -20°C to 120°C (-4°F to 248°F)
0°C to 650°C (32°F to 1202°F)
A400: 300°C to 1500°C (572°F to 2732°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Measurement analysis
Standard functions: 10 spotmeters, 10 boxes, 3 Deltas, 1 isotherm, 1 iso-coverage, 1 reference temperature
Automatic hot/cold detection: Max./min. temperature value and position shown within box
Scheduled response: SFTP (image), SMTP (image and/or measurement data/result)
Measurement frequency: Up to 10 Hz
Measurement result read-out: Yes; common protocols include EtherNet/IP, Modbus TCP, MQTT, and REST API
Dynamic Range: 16-bit
Alarm
Alarm function: On any selected measurement function; digital in; internal camera temperature
Alarm output: Yes: common output includes e-mail, EtherNet/IP, Modbus TCP, RESTful API, and ONVIF (advanced only)
Video streaming, RTSP protocol
Unicast: Yes
Multicast: Yes
Multiple image streams: Yes
RTSP protocol - video stream 0
Source: Visual, IR, MSX®
Contrast enhancement: FSX®, histogram equalization (IR only)
Overlay: With, without
Pixel format: YUV411
Encoding: H.264/MPEG4/MJPEG
RTSP protocol - video stream 1
Source: Visual
Overlay: No
Pixel format: YUV411
Encoding: H.264/MPEG4/MJPEG
Ethernet
Interface: Wired; Wi-Fi*
Connector types: M12 8-pin X-coded, female; RP-SMA, female
Ethernet type & standard: 1000 Mbps, IEEE 802.3
Ethernet power: Power over Ethernet, PoE IEEE 802.3af class 3
Ethernet protocols: Include EtherNet/IP, Modbus TCP, and MQTT
Digital input/output
Connector type: M12 Male 12-pin A-coded (shared with ext. power)
Digital input: 2× opto-isolated, Vin (low) = 0-1.5 V, Vin (high) = 3-25 V
Digital output: 3× opto-isolated, 0–48 V DC, max. 350 mA (derated to 200 mA at
60°C). Solid-state opto relay, 1× dedicated as fault output (NC)
Power system
Connector type: M12 Male 12-pin A-coded (shared with Digital I/O)
Power consumption: 7.5 W at 24 V DC typical; 7.8 W at 48 V DC typical; 8.1 W at 48 V PoE typical
Wi-Fi*
Connector type: Female RP-SMA
General
Base Mounting: 4× M4 on 4 sides
Housing material: Aluminium
Size (L x W x H): 123 × 77 × 77 mm (4.84 × 3.03 × 3.03 in)
Weight: 0.82 kg (1.8 lb), camera only
