Applications
• Conductivity testing on raw materials for sorting and quality assurance
• Inspection of alloys in coinage (e.g. conductivity of Euro coins)
• Assessment of the hardness and strength of heat-treated materials
• Checking for heat damage, material fatigue and cracks
• Estimation of the phosphorous content in copper alloys or copper-bearing materials
• Tracking of precipitation processes, e.g. in Cu-Cr alloys
• Verification of the homogeneity of alloys
• Scrap sorting
Features
• Measurements pursuant to ASTM E 1004 and DIN EN 2004-1
• SMP350 with probe FS40 fulfills Boeing specification BAC 5651
• Measurement frequencies ranging from 15 kHz to 2 MHz, depending on the probe
• Measurement range: 0.5 – 65 MS/m or 1 – 112% IACS
• Measurement precision at ambient temperature: ±0.5% of reading
• Operating temperature: 0 – 40 °C
• Lift-off compensation to 500 μm
• Smallest diameter measurement area without noticeable influence on the reading: 13 mm
• Connector for electrical conductivity probe, with or without integrated temperature sensor
• Connector for optional temperature sensor TF100A
• USB communication and printer port
• Power supply via battery or mains electricity
• Included in the shipment: Carrying case, power supply, battery set, carrying strap and protective cover for the instrument, Cu reference standard, USB cable
