Fanstel BM833A ອາເດັດເຕີ USB nRF52811 Module

Core: ARM Cortex M4

Range: 680 m

Width: 15 mm

Height: 1.9 mm

Length: 10.2 mm

Antenna: PCB

Protocol: BLE, Bluetooth 5.1

Data Rate: 2 Mb/s

Frequency: 2.4 GHz

Shielding: Unshielded

Dimensions: 10.23 mm x 15 mm x 1.9 mm

Memory Size: 192 kB, 24 kB

Sensitivity: - 97 dBm

Unit Weight: 10.117 g

Output Power: 4 dBm

Interface Type: I2C, I2S, SPI, UART

Mounting Style: SMD/SMT

Moisture Sensitive: Yes

Receiver Sensitivity: - 97 dBm

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.7 V

Antenna Connector Type: Chip

Operating Supply Voltage: 1.7 V to 3.6 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE

Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
