Faithful FSF-102B-1600X ກ້ອງຈຸລະທັດ (40X-1600X)

Trinocular

Total Magnification: 40X-1600X

Eyepieces: WF10X，WF16X

Objectives: Achromatic 4X, 10X, 40X(S), 100X (S Oil）

Lens Tube: flow/30°articulated; trinocular; Inclined a cylindrical tube, Rotate 360°, papillary distance: 55-75mm, containing: CCD port

Condenser: Abbe TypeNA= 1.25,With Adjustable Diaphragm And Filter Holder

Illumination: bromine tungsten lamp 6V/20W, Brightness can adjust

Focus formation: Coarse Adjustment Range：22mm, Fine Adjustment Range 1.3mm

Working Stage: Planform size：140mmX140mm, move range：75*45mm

Options: LED light
