Power:-144~144kW
Voltage: 0 ~ 1500V
Current: -320~320A
Resistance: 0.188~938Ω
Size( WxHxD): 5kW~18kW：482.6mm x 132.5mm x 740.0mm, including output protective cover
Weight: 5kW≈18kg, 10kW≈25kg, 15kW≈32kg
AC input: 3Ø AC input, 340VAC～480VAC, 47Hz～63Hz
Power factor: 0.99(typical)
Efficiency: ＞93% (typical)
Output voltage: 0~rated value (max 2250V, set via menu, input through numeric keys or rotary knob)
Output current: 0~rated value( max 10000A, set via menu, input through numeric keys or rotary knob)
Output power: 0~rated value(max 180kW, set via menu, input through numeric keys or rotary knob)
V measurement accuracy: 0.05%+0.05%F.S.
I measurement accuracy: 0.1%+0.1%F.S.
V/I monitoring: V/I monitoring voltage: DC 0～5V
Display: 4.3-inch TFT color LCD, support simplified Chinese, traditional Chinese and English
Operation way: Function keys, numeric keys and rotary knob (double knob for V/I respectively)
Transient response: For a 10%~90% load change, the amount of time for the power supply voltage resumes to 0.75%accuracy range of rated value is less than 2ms
Parallel: Max 10 identical models through master-slave parallel
Protection: OVP, OCP, OTP, OPP, LVP etc.
Communication: LAN, USB optional GPIB, CAN, RS485）
Protocol: SCPI, MODBUS, CAN-Open (optional) protocol
Work temperature: 0℃~40℃
Storage temperature: -20℃~70℃
Using altitude: ＜2000m
Cooling way: Air cooling, intelligent fan control
