Width: 4.7 mm
Height: 16.3 mm
Length: 10.67 mm
Fall Time: 100 ns
Rise Time: 200 ns
Technology: Si
Unit Weight: 2 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 P-Channel
Qg - Gate Charge: 39 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 100 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 17 ns
Typical Turn-Off Delay Time: 45 ns
Id - Continuous Drain Current: 16.5 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 9.9 S
Rds On - Drain-Source Resistance: 190 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 4 V
