Width: 1.9 mm
Height: 0.8 mm
Length: 3 mm
Fall Time: 5 ns
Rise Time: 5 ns
Technology: Si
Unit Weight: 67 mg
Channel Mode: Enhancement
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 5.6 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.6 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8 ns
Typical Turn-Off Delay Time: 21 ns
Id - Continuous Drain Current: 4.8 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 14 S
Rds On - Drain-Source Resistance: 32 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1 V
