Width: 1.25 mm
Height: 1.1 mm
Length: 2 mm
Fall Time: 8 ns
Rise Time: 8 ns
Technology: Si
Unit Weight: 28 mg
Channel Mode: Enhancement
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 P-Channel
Qg - Gate Charge: 1.5 nC
Number of Channels: 2 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 300 mW
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 55 ns
Id - Continuous Drain Current: 410 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 0.9 S
Rds On - Drain-Source Resistance: 1.1 Ohms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 1.5 V
