Wavelength:
Operating wavelength range (nm): 1350 - 1510
Operating wavelength range at 13 dBm (nm) : 1430 - 1490
Wavelength uncertainty a (pm) : ±5 (typical); ±20
Wavelength repeatability b (pm) : ±5 (typical)
Wavelength stability d (pm): ±5
Wavelength resolution setting (pm): 1
Sweep control:
Maximum speed (nm/s) : 200
Adjustable speed (nm/s) : 0.5, 1, 2, 5, 10, 20, 50, 100, 200 with bidirectional scanning
Mode-hop-free operation : Active mode-hop cancelation
Minimum wavelength sweep trigger resolution (pm) : 0.5
Optical power:
Maximum output power (dBm) : 14
Nominal output power over full wavelength range (dBm) :
Power stability d (dB) : ±0.01 (typical)
Spectral characteristics:
Linewidth e (10 µs integration time) (kHz) : < 25 (typical)
Linewidth e (100 µs integration time) (kHz) : < 250 (typical)
Side mode suppression ratio (SMSR) : > 50 (typical)
Signal-to-source spontaneous emission ratio g (SSSER) (dB) : 90 (typical)
Signal-to-total-source spontaneous emission ratio h (STSSER) (dB): 75 (typical)
Relative intensity noise i (RIN)(dB/Hz) : –150 (typical)
Optical output:
Optical fiber type : PM optical fiber, FC/APC connector
PER (dB): 17 (typical)
SPECIFICATIONS – HARDWARE:
Environmental conditions:
Operating temperature : 15 °C to 35 °C (59 °F to 95 °F)
Operating humidity : < 80% (non-condensing)
Warm-up time (hour) : 1
Physical footprint:
Size (L x H x D): 217 mm x 173 mm x 441 mm (8 9/16 in x 6 13/16 in x 17 3/8 in)
Weight : 9 kg (20 lb)
Connectivity:
Monitor : 7 in capacitive touchscreen
Remote communication : Ethernet RJ45 LAN 10/100/1000 Mbit/s
Electrical BNC ports : 1x trigger IN, 1x trigger OUT, power monitoring and wavelength monitoring
USB ports : USB 3.0 (1), USB 2.0 (2)
Security:
Laser safety : Class 1M
Power supply : 100 - 240 V ~; 50/60 Hz; 0.65 - 0.3 A
Accessories (sold separately) : Rackmount 4U tablet accommodating 2 units
