TECHNICAL SPECIFICATIONS
Wavelength range (C-band): 1527.99-1567.95 nm (191.2-196.2 THz)
ITU channels: ITU-T G694.1 channels 12-62
Channel spacing: DWDM 100 GHz
Dynamic range per channel (dBm): 10 to –40
Maximum total safe power (dBm): 20
Absolute power uncertainty (dB) (typical): 1
ORL (dB): > 35
Measurement time (s): < 3
BUILT-IN POWER METER SPECIFICATIONS (GeX) (OPTIONAL)
Calibrated wavelengths (nm): 850, 1300, 1310, 1490, 1550, 1625, 1650
Power range (dBm): 27 to —50
Uncertainty (%): ±5 % ± 10 nW
Display resolution (dB): 0.01 = max to —40 dBm; 0.1 = —40 dBm to —50 dBm
Automatic offset nulling range Max power to" —30 dBm
Tone detection (Hz): 270/330/1000/2000
VISUAL FAULT LOCATOR (VFL) (OPTIONAL)
Laser, 650 nm ± 10 nm
CW/Modulate 1 Hz
Typical Pout in 62.5/125 µm: > –1.5 dBm (0.7 mW)
Laser safety: Class 2
