SPECTRAL MEASUREMENT
Wavelength range: 1527.99 - 1565.90 nm (196.20 - 191.45 THz)
Channel spacing: DWDM 50 GHz and 100 GHz
Wavelength uncertainty (nm): ±0.1
POWER MEASUREMENT
Dynamic range per channel (dBm): 10 to –48
Maximum total safe power (dBm): 28
Absolute power uncertainty (dB): ±1
OPTICAL MEASUREMENT
Optical rejection ratio at 0.4 nm (50 GHz) (dB): 40
PDL (dB) : ±0.3
ORL (dB) : > 35
Measurement time (s) : < 0.5
GENERAL SPECIFICATIONS
Temperature
Operating: —10 °C to 50 °C (32 °F to 120 °F)
Storage: —20 °C to 50 °C (—4 °F to 120 °F)
Connectors: Interchangeable SC and FC fiber adapters. Choice of UPC or APC model.
Size (H x W x D): 194 mm x 99 mm x 40 mm (7 5/8 in x 3 7/8 in x 1 1/2 in)
Weight: 0.72 kg (1.6 lb)
Battery: Rechargeable NiMH - 4 hours operating time
Power supply: 100-240 universal US, GB, EU, AU mains
