Moving Area (X/Y/Z): 400/400/100 mm
Max. Speed: XY/Z：400 / 320 mm/sec
Soldering Head Distance: MIN. Distance 90mm / MAX. Distance 165mm
Program System: CF Card / USB
Drive System/ Stepping Motor: Micro Stepping Motor
Max.Temperature: Max. 460°C
Solder Wire Diameters: ø 0.4 ~ 1.2 mm
Clean System: Air / Brush
Power Supply: 100V~230V/450W
Working Humidity: 20-85% no condensation
Weight: 75 kg
Working Area(X/Y): 400 /300 mm
Repeatability: +/- 0.01 mm/ Axis
Data Memory capacity: 9999 points/prog. 100 programs
Display: Teach Pendant LCD
Teaching Method: Teach Pendant
Temp.Control Power: 150 W (Optional:200W ; 280W )
Solder Feeder System: Stepping Motor
Air Pressure: 5~7 kg/cm²
Working Temp.: 10-40°C
Dimensions WxDxH: 791x730x860.5mm(Include exhaust pipe)
