ETA-USA ODC75-12SC110 ອິສເອລເທດ 75W 40V-160Vi 12Vo 6.25A DIP-9

Width: 57.7 mm (2.272 in)

Height: 15 mm (0.591 in)

Length: 60.8 mm (2.394 in)

Industry: Industrial

Dimensions: 61 mm x 57.9 mm x 15 mm

Efficiency: 90%

Adjust Type: Adjustable

Output Power: 75 W

Input Voltage: 40 V to 160 V

Mounting Style: Through Hole

Isolation Voltage: 2.25 kV

Number of Outputs: 1 Output

Input Voltage - Max: 160 V

Input Voltage - Min: 40 V

Input Voltage, Nominal: 110 V

Output Current-Channel 1: 6.25 A

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
