System: Balanced Temperature Control system (BTC system)
Performance:
Temperature range: −70 to ＋180℃ (−94 to ＋356℉)
Allowable heat load: 8 kW (−20℃ or more)
Inside dimensions: W800 × H500 × D400 mm
Outside dimensions: W1000 × H1808 × D1915 mm
Capacity: 160 L
Weight: 950 kg
Utility requirements:
Allowable ambient conditions: ＋5 to ＋35℃ (＋41 to ＋95℉)
Power supply: 380V AC 3φ 50Hz, 61A
Cooling water supply pressure: 0.2 to 0.5 Mpa (2 to 5 kg/cm2G)
Cooling water supply rate: 4100L/h (at reference water temp. ＋25℃)
Piping connection size: Carbon steel pipe, ID 32 mm (drain and supply)
Operating cooling water temp. range: ＋5 to ＋32℃ (＋41 to ＋89.6℉)
Accessories
• Flat cable port rubber plug (Silicone sponge rubber): 2
• Specimen basket: 2 (18-8 Cr-Ni stainless steel: 5 mesh per inch)
W700×H40×D346 mm/ load capacity 5kg
• Shelf brackets (7 positions available, pitch 60mm): 4
• Cartridge fuse:
200V AC
Type B, 250V 6A: 1
250V 4A: 1
220V AC, 380V AC, 400V AC
Type B, 250V 4A: 1
250V 5A: 1
250V 6A: 1
• Specimen temperature measuring thermocouple:1
• Specimen temperature input connector: 1
• Strainer R11/4 in. (32A): 1
• Nipple R11/4 in. (32A): 1
• Strainer element (#30 mesh): 1
• Operation manual: 1 set
• Warranty card: 1
*Power cable is optional, not equipped as standard fitting.
