- Specifications
Size of Spectrometer: 560mm*380mm*410mm
Size of sample chamber：460mm*310mm*95mm
Size of Vacuum sample chamber：Φ150mm×75mm
Weight: 45Kg
Element Range：S16-U92
Analysis content range：1ppm- 99.99%
Detector：AmpTek high resolution SDD
DPP Analyzer: 4096 Channel DPP analyzer
Excitation Source：50W X-ray tube
HV unit：0-50kV
Power supply：220ACV 50/60HZ
Environment：-10 °C to 35 °C
- Standard Accessories
- Standard
Ag- Calibration standard
Vacuum pump
Sample cup
USB cable
Power supply cable
Test Mylar
Calibration report
Warranty card
- Optional
Mill machine
Sample pressing machine
Drying oven
Fusing bead machine
Balance
Mineral Standard samples
Power stabilizer
Features and benefits
1. Faster - Due to the higher sample signal flux that can be obtained within a unit of time, the measurement time is greatly reduced. It only takes 100 seconds to achieve the measurement effect of 200 seconds of ordinary version instruments.
2. More accurate - The unique multi-channel analyzer DPP can achieve a linear count rate of more than 100,000 cps while ensuring the optimal spectral resolution, usually better than 130 eV (the ordinary Si-pin detector is 160 eV), to better separate the spectra of different elements. At the same time, the powerful FP (basic parameter algorithm) software based on Windows reduces the absorption and enhancement effect between matrix elements, and takes into account the interference of different matrices on the change of spectral intensity, which raises the test accuracy to a new level.
3. More stable - Using the super-large area 25 mm2 beryllium window SDD detector (the ordinary Si-pin detector is 6mm2), this detector can obtain 2-3 times the spectral intensity (count rate CPS) of the ordinary detector under the same sample excitation conditions, thus achieving better test stability and long-term reproducibility. Compared with the traditional Sipin version desktop instruments, the EDX8000B spectrometer can operate at full power, thus achieving a more stable and reliable test performance.
