Number of process chambers: 1 unit of 2-Glove Process Chamber
Electrical configuration: 220-240 VAC 50/60 Hz
Pod flange design: with pod flange
Passthrough chamber design: Left PTC Only
Door design: without doors
Docked unit: CCXBR-220L
CCXBR 220L:
External Dimensions (W x D x H): 985 x 960 x 1720 mm
Internal Dimensions (W x D x H): 600 x 550 x 650 mm
Rapid decontamination system (RDS): without RDS
Main Chamber:
External Dimensions (W x D x H): 1364 x 1150 x 2350 mm
Internal Dimensions (W x D x H): 1312 x 700 x 845 mm
Passthrough Chamber:
External Dimensions (W x D x H): 770 x 1150 x 2350 mm
Internal Dimensions (W x D x H): 720 x 700 x 845 mm
Process Chamber Environment: ISO Class 5 / Grade A Environment Prefilter: HEPA H14 Filter with Gasket Seal and Integral Mesh Guard
Downflow Filter: HEPA H14 Filter with Gasket Seal and Integral Mesh Guard
1st Stage Exhaust Filter: HEPA H14 Filter with Gasket Seal and Integral Mesh Guard
2nd Stage Exhaust Filter: HEPA H14 Filter with Gasket Seal and Integral Mesh Guard
Lighting Level: ≥ 600 Lux
Sound Level: < 65 dBA
Compressed Air Requirement: 6-12 Bar-g Pressure at 5 L/sec
Optional Accessories:
Glove Leak Tester: ✓
RTP Alpha Port: ✓
RTP Beta Container or Liner: ✓
Temp and RH Control: ✓
BIBO Exhaust Filter: ✓
Tri-Gas Control: ✓
N₂ Ports: ✓
Non-viable Particle Counter: ✓
Viable Air Sampler: ✓
Sterility Test Pump Integration: ✓
