X–Ray Tube
Tube Style: Sealed Tube
Tube Voltage: 160KV
Tube Current: 2.5mA
Optical Tube Power: 400W
Detail Resolution: 0.4mm
Cooling Mode: Air Cooling
X–Ray
X-Ray Rotation Angle: Coaxial ±45˚ tilt is possible
FlatPanel Detector
Effective Area: 432mm*432mm
Pixel Size: 2816×2816
A/D Change: 16Bit
Sample Table
Axis Z: 800mm
Axis X: 500mm
Axis Y: 500mm
Axis R: Horizontal 360° rotation
Maximum Bearing Capacity: Maximum load 100KG
Software and Image Processing Capabilities
Measuring Function: The bubble crack of the test sample was determined by software
Software Processing power: Image inversion, Sharpening, Histogram,Binarization for better analysis of X-RAY images
Image Enhancement: Automatic image enhancement, image reverse color, image edge smoothing, texture
Software Protection Capability: When the machine is unmanned, the X-ray is automatically disconnected after 20 minutes, thus extending the life of the X-ray tube
Radiation Safety
Whole Machine Surface less than 1usv/h: <1usv/h
Safety Door Automatic Interlock Protection Function: When the X-ray is turned on, the safety door automatically locks for protection
Radiation Door: Manual button on and off
Computer
Brand: Advantech
System: WIN10
CPU: I5
X-Ray subject
Size: L1822 mm* W1535 mm* H1929 mm
Weight: about 4500kg
Power
Power Supply: AC110-230VAC,50/60Hz
Applications:
Comprehensive inspection and testing of cast components
Ensures structural integrity and quality performance
Detection of internal defects in casting materials
Verification of dimensional accuracy and consistency
