X-Ray Tube
Tube Style: Sealed Tube
Tube Voltage: 160KV
Tube Current: 2.5mA
Optical Tube Power: 400W
Detail Resolution: 0.4-0.8mm
Cooling Mode: Air Cooling
Plat Panel Detector
Effective Imaging Area 432mm*432mm
Pixel size: 2816×2816mm
A/D change: 16Bit
Sample Table
Axis X: 400mm
Axis Y: 400mm
Sample Table: 500*500mm
Effective Visual Range: 400*400mm
Software and Image Processing Capabilities
Measuring Function: The bubble crack of the test sample was determined by software
Software Processing Power: Image inversion, sharpening, histogram, binarization for better analysis X-RAY picture
Image Enhancement: Automatic image enhancement, Image reverse color, Image edge smoothing, Texture
Software Protection Capability: When the machine is unmanned, the X-ray is automatically disconnected after 20 minutes, thus extending the life of the X-ray tube
Radiation Safety
The machine surface is less than 1usv/h: <1usv/h
Safety door automatic interlock protection function: when the X-ray is turned on, the safety door automatically locks for protection
X-Ray Subject
Size: L1005mm*W1180mm*H1625mm
Weight: about 1400kg
Power
Power Supply Mode: AC110-230VAC,50/60Hz
Applications:
Comprehensive inspection and testing of cast components
Ensures structural integrity and quality performance
Detection of internal defects in casting materials
Verification of dimensional accuracy and consistency
