Measuring Geometrics: d/8°, DRS spectral engine, fixed aperture: 8mm viewing/12mm illumination
Light Source: Gas filled tungsten lamp
Illuminant Types: C, D50, D65, D75, A, F2, F7, F11, F12
Standard Observers: 2° and 10°
Spectral Range: 400-700nm
Memory: 1,024 standards with tolerances, 2,000 samples
Measurement Range: 0 to 200% reflectance
Measuring Time: Approximately 2 seconds
Inter-Instrument Agreement: 0.40 ΔE*ab
Repeatability: 0.10 ΔE*ab on white ceramic (standard deviation)
Lamp Life: Approximately 500,000 measurements
Power Supply: Removable (Ni-metal hydride) battery pack; 7.2DC rated @1450mAh
Measurements per Charge: 1000 measurements within 8 hour period
Weight: 1.1kg
Dimensions: 109 x 83 x 195mm
Certificate Available Certificate of Calibration: issued for Fixed Calibration equipment and shows readings and traceability
Packing List: Elcometer 6075/1, calibration standards, AC adaptor, carry case & operating instructions
Elcometer 6085 Portable Sphere Spectrophotometer
Technical Specification
|
Part Number |
Description |
Certificate |
|
K6085M001 |
Elcometer 6085 Ci60 Portable Sphere Spectrophotometer |
• |
|
K6085M002 |
Elcometer 6085 Ci62 Portable Sphere Spectrophotometer |
• |
|
Measuring Geometrics |
d/8°, DRS spectral engine, fixed 8mm aperture Simultaneous SPIN / SPEX |
|
|
Light Source |
Gas filled tungsten lamp |
|
|
Illuminant Types |
A, C, D50, D55, D65, F2, F7, F11 & F12 |
|
|
Standard Observers |
2° and 10° |
|
|
Spectral Range |
400-700nm |
|
|
Memory |
1,000 standards with tolerances, 4,000 samples |
|
|
Measurement Range |
0 to 200% reflectance |
|
|
Measuring Time |
Approximately 2 seconds |
|
|
Inter-Instrument Agreement (Ci60) |
CIE L*a*b*: |
|
|
Inter-Instrument Agreement (Ci62) |
CIE L*a*b*: |
|
|
Short-term Repeatability* |
Ci60 - 0.10 ∆E*ab on white ceramic (standard deviation) |
|
|
Lamp Life |
Approximately 500,000 measurements |
|
|
Power Supply |
Removable battery pack; 7.4 VDC, 2400 mAh |
|
|
Measurements per Charge |
1000 measurements within 8 hour period |
|
|
Weight |
1.05kg (2.32lbs.) |
|
|
Screen Display |
3.2 inch backlit Colour Graphic LCD |
|
|
Dimensions |
109 x 91 x 213mm (4.3 x 3.6 x 8.4”) |
|
|
Packing List |
Elcometer 6085 Ci60, calibration standards, calibration certificate for standards, AC adaptor, mains leads (UK & EUR), carry case & operating instructions |
|
|
Packing List |
Elcometer 6085 Ci62, calibration standards, calibration certificate for standards, AC adaptor, mains leads (UK & EUR), carry case & USB cable, operating instructions |
|
