INPUT:
• Voltage (AC): 200-240V
• Apparent Power: 600VA
• Frequency: 50/50Hz+/-5%
AC WITHSTAND VOLTAGE:
• Output Rating (AC): 5kV/40mA
• Output Voltage Range: 0-5.00kV
• Voltage Resolution: 0.01kV
• Voltage Accuracy: +/-(1% of setting + 0.5% of range)
• Current Measurement Range (Total): 0.000-40.00mA
• Current Resolution (Total): 0.001/0.01/0.1mA
• Current Accuracy (Total):
0.000-4.000mA: +/-(2% of reading + 3 counts)
3.50-100.0mA: +/-(2% of reading + 6 counts)
DC WITHSTAND VOLTAGE:
• Output Rating (AC): 6kV/10mA
• Output Voltage Range: 0-6.00kV
• Voltage Resolution: 0.01kV
• Voltage Accuracy: +/-(1% of setting + 0.5% of range)
• Current Measurement Range: 0.0nA-10mA
• Current Resolution: 0.1nA/0.001uA/0.01uA/0.1uA/0.001mA/0.01mA
• Current Accuracy:
0.0-400.0nA/0.350-4.000uA/3.50-40.00uA: +/-(2% of reading + 10 counts) Low range is ON
35.0-400.0uA/0.300-4.000mA/3.5-10.00mA: +/-(2& of rading + 2 ocunts)
INSULATION RESISTANCE:
• Output Rating (AC): 6kV/5GΩ
• Output Voltage Range: 10-6000V
• Voltage Resolution: 1V
• Voltage Accuracy: +/-(1% of setting + 0.5% of range)
• Resistance Measurement Range: 0.100MΩ-50GΩ
• Resistance Resolution: 0.001/0.01/0.1/1MΩ
• Resistance Accuracy:
0.05-999.9MΩ under 10-29V: +/-(15% of reading + 2 counts)
0.05-999MΩ under 30-499V: +/-(7% of reading + 2 counts)
0.100-999.9MΩ under 500-6kV: +/-(2% of reading + 2 counts)
1Ω-9.999GΩ under 500-6kV: +/-(5% of reading + 2 counts)
10Ω-50GΩ under 500-6kV: +/-(15% of reading + 2 counts)
CONTINUITY (Optional):
• Output Rating (AC): 1A for 1.000Ω, 0.1A for 10.00Ω, 0.01A for 100.0Ω, 0.001A for 1kΩ, 0.0001A for 10kΩ
• Resistance Measurement Range: 0.000-10kΩ
• Resistance Resolution: 0.001/0.01/0.1/1Ω
• Resistance Accuracy: +/-(1% of reading + 3 counts)
GROUND BOND:
• Output Rating (AC): 32A/600mΩ/8V
• Output Current: 1.00-32.00A
• Current Resolution: 0.01A
• Current Accuracy: +/-(2% of setting + 0.5% of range)
• Output Voltage: 3.00-8.00V
• Voltage Resolution: 0.01V
• Voltage Accuracy: +/-(2% of setting + 0.5% of range)
GENERAL:
• Display: 4.3" Color Display (Touch Panel)
• Interface: Standard USB & RS232, Optional Ethernet, GPIB
• Dimension (WxHxD): 430x133x400 mm
• Weight: 20kg
