EEC EPV-530 PV Module ເຄື່ອງວິເຄາະຄວາມປອດໄພ (0.0 - 20.00 mA)
INPUT
• Voltage: 100 - 120Vac / 200 - 240Vac ±10% Auto Range
• Công suất biểu kiến: 1200 VA
• Frequency: 50/60 Hz ± 5%
DC WITHSTAND VOLTAGE
• Output Rating: 8000 Vdc / 20mA max
• Output Voltage Range: 0 - 8000 Vdc
• Voltage Resolution: 1 Vdc
• Voltage Accuracy: ± (1% of Setting + 0.5% Range)
• Current Measurement Range: 0.0 - 20.00 mA
• Current Resolution:
0.0 - 349.9 μA: 0.1 μA
0.350 - 20.00 mA: 0.001 / 0.01 mA
• Current Accuracy: ± (1% of Reading + 0.5% Range)
INSULATION RESISTANCE
• Output Rating: 6k Vdc / 50,000 MΩ
• Output Voltage Range: 100 - 6000 Vdc
• Voltage Resolution: 1 Vdc
• Voltage Accuracy: ± (1% of Setting + 0.5% Range)
• Resistance Measurement Range: 0.100 - 50,000 MΩ
• Resistance Resolution: 0.001 / 0.01 / 0.1 / 1 MΩ
• Resistance Accuracy:
0.100 - 999.9 MΩ under 100-499V: ±(8% of Reading+0.1% Range)
0.100 - 999.9 MΩ under 500 – 6000 Vdc
: ±(2% of Reading+0.1% Range)
1,000 - 9,999 MΩ under 500 – 6000 Vdc: ±(5% of Reading+0.1% Range)
10,000 - 50,000 MΩ under 500 – 6000 Vdc: ±(15% of Reading+0.1% Range)
GROUND BOND
• Output Rating: 40A / 600mΩ / 8Vdc Max.
• Output Current, dc: 3.00 - 40.00 A
• Current Resolution: 0.01A
• Current Accuracy: ± (2% of Setting + 0.5% Range)
• Resistance Measurement:
0 - 150 mΩ Under 30.1-40.0A
0 - 200 mΩ Under 10.1-30.0A
0 - 600 mΩ Under 3.0-10.0A
• Resistance Resolution: 1 mΩ
• Resistance Accuracy: ± (2% of Reading + 0.5% Full Range)
GENERAL
• Interface: Standard: USB , RS232, PLC Remote , Option: GPIB, Ethernet
• Display: 4.3" Color Display (Touch Panel)
• Dimension (W x H x D), mm: 430 × 133 × 400
• Weight: 25.1KG
