Relative Humidity and PPMv Ranges:
5 to 95% RH with all sensors, non-condensing conditions
0 to 999,999 PPMv with all sensors, non-condensing conditions
Accuracy (All Sensors):
±0.2°C (0.36°F) dew/frost point standard
±0.1°C (0.18°F) dew/frost point optional
±0.5% of full-scale pressure
Remote Sensors: Up to 250 feet (76 meters) from console with cable
Display Resolution:
0.1°C or °F
0.01 psia
0.1 PPMv below 1000 PPMv
1 PPMv above 1000 PPMv
Air Temperature Sensor Range: -100 to 250°C (-148 to 482°F), ±0.1°C accuracy
Sample Flow Rate: 0.5/5.0 SCFH (0.25 to 2.4 l/min)
Outputs (3 outputs available): 4 to 20 mA, 0 to 5 Vdc, RS-232
Display: 8-line LCD graphic data display, backlight, 3 parameters displayed simultaneously
Power Requirements: 90 to 230 VAC ±10%, 50 to 400Hz
Weight:
Bench-Top: 6 lb. (2.8 kg)
Rack Mount: 7 lb. (3.2 kg)
NEMA 4: 19 lb. (8.6 kg)
Dimensions:
Bench-Top with S3 Mounted: 11 in. W x 5.2 in. H x 17 in. D (27.9 cm W x 13.2 cm H x 43.2 cm D)
Rack Mount with S3 Mounted: 19 in. W x 7 in. H x 17 in. D (48.3 cm W x 17.8 cm H x 43.2 cm D), standard rack panel mounting dimensions
NEMA 4: 11.6 in. W x 13.6 in. H x 6.2 in. D (29.5 cm W x 34.6 cm H x 15.9 cm D)
