Max Load: 50kN (5000kgf, 5 tons)
Load Accuracy: Class 1 (optional: Class 0.5)
Testing Range: 2% ~ 100% F.S (optional: 0.4% ~ 100% F.S)
Load Resolution: 1/500000 F.S
Test Control Mode: 3 closed loop control, stress, strain and displacement
Deformation Measuring Range: 0.2% ~ 100% F.S
Deformation Accuracy: ±0.5%
Displacement Accuracy: ±0.5%
Displacement Resolution: 0.04 μm
Control System Parameters:
Control Mode: Force closed loop control, deformation closed loop control, displacement closed loop control
Force Control Speed Range: 0.001% ~ 5% F.S/s
Constant Force Control Accuracy: When the rate < 0.05% F.S/s, it is within ±2% of the set value; when rate ≥ 0.05% F.S/s, it is within ±0.5% of the set value
Deformation Control Speed Range: 0.001% ~ 5% F.S/s
Constant Deformation Control Accuracy: When the rate < 0.05% F.S/s, it is within ±2% of the set value; when rate ≥ 0.05% F.S/s, it is within ±0.5% of the set value
Main Frame Parameters:
Max Tensile Testing Space: 650 mm
Max Compression Testing Space: 550 mm
Test Width: 400 mm
Crosshead Speed Range: 0.001 ~ 500 mm/min
Overall Dimensions (LWH): 800x500x1900 mm
Power Supply: 1P 220V ±10%, 50-60Hz, 1KW
Net Weight: About 500 kg
Operating Temperature: 0 to +38 °C (+32 to +100 °F)
Humidity Range: 10% to 90% non-condensing
