Max Load: 10kN (1000kgf)
Load Accuracy: Class 1 (optional: Class 0.5)
Testing Range: 2%～ 100%F.S (optional: 0.4%～ 100%F.S)
Load Resolution: 1/500000FS
Test Control Mode: 3 closed loop control, stress, strain and displacement
Deformation Measuring Range: 0.2%～ 100%FS
Deformation Accuracy: ≤±0.5%
Displacement Accuracy: ≤±0.5%
Displacement Resolution: 0.04μm
Control System Parameters
Control Mode: Force closed loop control, deformation closed loop control, displacement closed loop control
Force Control Controls The Speed Range: 0.001%~5%FS/s
Constant Force Control Accuracy: When the rate is < 0.05%FS/s, it is within ±2% of the set value; when the rate is ≥0.05%FS/s, it is within ±0.5% of the set value;
Deformation Control Controls Speed Range: 0.001%~5%FS/s
Constant Deformation Control Accuracy: When the rate is < 0.05%FS/s, it is within ±2% of the set value; when the rate is ≥0.05%FS/s, it is within ±0.5% of the set value;
Main Frame Parameters
Max. Tensile Testing Space: 789mm
Max. Compression Testing Space: 789mm
Test Width: 315mm
Crosshead Speed Range: 0.001～ 500mm/min
Overall Dimensions (L*W*H): 663*430*1700mm
Power Supply: 1P 220V±10%,50-60HZ,500W
N.W.: About 180kg
Operating Temperature: 0 to +38°C (+32 to +100°F)
Humidity Range: 10% to 90% non-condensing
