Turret Automatic
Testing force
10g (0.098N), 25g (0.245N), 50g (0.49N), 100g (0.98N ), 200g (1.96N), 300g (2.94N), 500g (4.9N), 1000g (9.8N)
Hardness scale HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
HV Software system
5 million pixel camera; camera connect tube and adapter;
Professional HV/HK Indentation image measurement and analysis
software, support automatic measure mode and manual measure
mode, generate test report automatically in word / Excel format
Loading speed ≤0.05mm/sec
Indenter Standard Rectangular pyramid diamond indenter (136o±0.5o)
Resolution 0.025μm
Testing rang 5HV-3000HV
Screen 5.5’’ front color touch screen + 12.1’’ side color touch screen
Eyepiece 10X digital eyepiece
Objective lens 10X (Measurement), 40X (Measurement)
Total magnification 100X (For Measurement) , 400X (For Measurement)
Loading method Automatically (Load, dwell and unload the testing force)
Duration time 1-99s (each step is 1 second)
Maximum height 90mm
Throat depth 95mm
Machine size & N.W 405*290*480mm (L×W×H) 40kg
Packing size & G.W 850x420x600mm( LxWxH) 56kg
Light Source LED cold light source
Power Supply 220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table
Dim.:100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Executed Standard GB/T4340, ASTM E384 & E92, EN-ISO 6507, JIS B-7734
