TurretAutomatic
Test force:
10gf, 25gf, 50gf, 100gf, 200gf, 300gf, 500gf, 1000gf
0.098N, 0.246N, 0.49N, 0.98N, 1.96N, 2.94N, 4.90N, 9.80N
Test Range:1HV~2967HV
Test Mode:HV/HK
Loading Method:Automatic (Loading/Dwell/Unloading)
Conversion Scale:HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Data Output:Built-in Printer，RS232 Interface
Hardness Reading:LCD Display, Data can be saved
Objective:10× (Observe)，20× (Measure)，40× (HV Measure), 40× (HK Measure)
Eyepiece:10×
Total Magnification:100× ，200× ，400× , 400×
Resolution:0.03μm ，0.015μm
Dwell Time:0~95s
Light Source:Halogen Lamp
X-Y Test Table:Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm
Max. Height of Specimen:90mm
Throat120mm
Power Supply:AC220V，50Hz
Execute Standard:ISO 6507，ASTM E384，JIS Z2244，GB/T 4340.2
Dimension:495×305×550mm，Packing Dimension: 600×360×800mm
Weight:Net Weight: 35kg，Gross Weight: 44kg
Packing List:
Instrument Main Body1 set
10× Digital Measuring Eyepiece1 pc
Diamond Micro Vickers Indenter1 pc
Diamond Knoop Indenter1 pc
10×, 20×, 40×, 40× Objective4 pcs
Weights7 pcs
Power Cable1 pc
Cross Test Table1 pc
Thin Specimen Test Table1 pc
Flat Clamping Test Table1 pc
Filament Clamping Test Table1 pc
Level1 pc
Horizontal Regulating Screw4 pcs
Halogen Lamp 12V、15~20W1 pc
Fuse 1A2 pcs
Screw Driver1 pc
Inner Hexagon Spanner1 pc
Color Filter1 pc
Plastic Absorbing Plate1 pc
Hardness Block 400~500 HV0.21 pc
Hardness Block 700~800 HV11 pc
Hardness Block 700~800 HK11 pc
Anti-dust Cover1 pc
Usage Instruction Manual1copy
