Rockwell Test Force:60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Brinell Test Force:30kgf (294.2N), 31.25kgf (306.5N), 62.5kgf (612.9N), 100kgf (980.7N), 187.5kgf (1839N)
Vickers Test Force:30kgf (294.2N), 100kgf (980.7N)
Indenter:Diamond Rockwell Indenter, Diamond Vickers Indenter, ф1.588mm, ф2.5mm, ф5mmBall Indenter
Hardness Reading:Rockwell: Dial, Brinell & Vickers: Check Hardness Table
Magnification:Brinell: 37.5×, Vickers: 75×
Resolution:Rockwell: 0.5HR, Brinell: 4μm, Vickers: 2μm
Dwell Time:2~60s
Max. Height of SpecimenRockwell: 175mm, Brinell: 100mm, Vickers: 115mm
Throat:165mm
Power Supply:AC220V，50Hz
Execute Standard:ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.2 ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2 ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimension:520×240×700mm，Packing Dimension: 650×370×950mm
Weight:Net Weight: 80kg，Gross Weight: 105kg
Packing List:
Instrument Main Body1 set
Diamond Rockwell Indenter1 pc
Diamond Vickers Indenter1 pc
ф1.588mm, ф2.5mm, ф5mmBall Indentereach 1 pc
Slipped Test Table1 pc
Middle Plane Test Table1 pc
Large Plane Test Table1 pc
V-shaped Test Table1 pc
15× Digital Measuring Eyepiece1 pc
2.5×, 5× Objectiveeach 1 pc
Microscope System (include the inside light and outside light)1 set
Hardness Block 150~250 HBW 2.5/187.51 pc
Hardness Block 60~70 HRC1 pc
Hardness Block 20~30 HRC1 pc
Hardness Block 80~100 HRB1 pc
Hardness Block 700~800 HV301 pc
Weights 0, 1, 2, 3, 45 pcs
Power Cable1 pc
Fuse 2A2 pcs
Horizontal Regulating Screw4 pcs
Level1 pc
Spanner1 pc
Screw Driver1 pc
Anti-dust Cover1 pc
Usage Instruction Manual1 copy
