Test Force
1. kgf:62.5, 100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000
2. N:612.9, 980.7, 1226, 1839, 2452, 4903, 7355, 9807, 14710, 29420
Test Range:3.18～653HBW
Loading Method:Automatic (Loading/Dwell/Unloading)
Hardness Reading:Touch Screen Display
Conversion Scale:HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS
Data Output:Built-in Printer, RS232 Interface
Shifting between Objective and IndenterAutomatic Recognition and Shifting (Three Indenters, Two Objectives)
Objective:1× ，2×
Eyepiece: 20×
Total Magnification:20× ，40×
Resolution:1.25μm ，0.625μm
Dwell Time:0~60s
Max. Height of Specimen:260mm
Throat:150mm
Power Supply:AC220V，50Hz
Execute Standard:ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2
Dimension:535×260×890mm，Packing Dimension: 820×460×1170mm
Weight:Net Weight: 150kg，Gross Weight: 180kg
Packing List:
Instrument Main Body1 set
20× Digital Measuring Eyepiece1 pc
1×, 2× Objectiveeach 1 pc
Ф2.5mm, Ф5mm, Ф10mm Ball Indentereach 1 pc
Small Plane Test Table1 pc
Large Plane Test Table1 pc
V-shaped Test Table1 pc
Power Cable1 pc
Hardness Block 150~250 HBW 10/30001 pc
Hardness Block 150~250 HBW 5/7501 pc
Fuse 2A2 pcs
Anti-dust Cover1 pc
Usage Instruction Manual1 copy
