System:
Relative humidity: 10–95%
Weight (complete system): 7.2 kg [15.9 lbs]
Carrying case WxHxD: 500x415x170 mm [19.7”x16.3”x6.7”]
Measuring units :ELM40 / ELS40
Type of detector: True PSD 30 mm [1.2”]
Wireless communication Class I Bluetooth® wireless technology
Operating time: >4 h
Resolution: 0.001 mm [0.05 mils]
Measuring errors: ±1% +1 digit
Measurement range: Up to 10 m [33 feet]
Type of laser: Diode laser
Laser wavelength; 635–670 nm
Laser class: Safety class II
Laser output: <1 mw="" span="">
Electronic inclinometer: 0.1° resolution
Thermal sensors: -20–60 °C
Environmental protection: IP class 65
Temperature range: -10–50 °C
Housing material Anodized aluminium / ABS plastics
Dimensions WxHxD: 69.0x61.5x41.5 mm [2.72”x2.42”x1.63”]
Weight 172 g [6.0 oz]
Display unit E52
Type of display/size VGA 5.7” colour screen, backlit LED
Displayed resolution: 0.001 mm / 0.05 thou
Internal battery (fixed) Heavy duty Li Ion chargeable
Operating time Approx. 30 hours (at typical user cycle)
Temperature range: -10–50 °C
Connections USB A, USB B, Easy-Laser® units, Charger
Wireless communication Class I Bluetooth® wireless technology
Internal memory >100 000 measurements can be saved
Help functions Calculator, Unit converter
Environmental protection IP class 65
Housing material PC/ABS + TPE
Dimensions WxHxD: 250x175x63 mm [9.8”x6.9”x2.5”]
Weight: 1020 g [2.3 lbs]
Cables
Charging cable (splitter cable) Length 1 m [39.4”]
USB cable Length 1.8 m [70.8”]
Brackets etc.
Shaft brackets Type: V-fixture for chain, width 18 mm [0.7”].
Shaft diameters: 20–450 mm [0.8”–17.7”]
Material: anodised aluminium
Rods Length: 120 mm, 60 mm [4.72”, 2.36”] (extendable)
Material: Stainless steel
EasyLink™ Data base software
System requirements: Windows® XP, Vista, 7, 8. For the export functions, Excel
2003 or newer must be installed on the PC.
A complete system contains
1 Measuring unit M
1 Measuring unit S
1 Display unit
2 Shaft brackets with chains
2 Extension chains
4 Rods 120 mm [4.72”]
4 Rods 60 mm [2.36”]
1 Measuring tape 3 m [9.8’]
1 USB memory with EasyLink™ PC software
1 USB cable
1 Charger (100–240 V AC)
1 DC split cable for charging
1 DC to USB adapter, for charging
1 Shoulder strap for display unit
1 Quick reference manual
1 CD with documentation
1 Carrying case
